As part of Yamaha's no-compromise design policy, Yamaha created the AVENTAGE MX-A500 11-Channel Amplifier. This machine features an advanced chassis with strong rigidity. Chassis stiffness is enhanced by an H-shaped cross frame that boosts mechanical strength, by adopting aluminum side panels that increase the stiffness of the housing and by a three-ply structure with independent top cover and side panels. The interior of the unit has been precisely planned, circuit-routed and built so that the left and right channels are physically and electrically isolated. The MX-A5000 uses a current feedback power amp with a three stage Darlington circuit that has superior phase properties and is resistant to speaker impedance fluctuation.
The MX-A5000 was designed to allow flexible system building when matched with the CX-A500 Preamplifier. They both complement each and take advantage of their 11-channel output maximizing the Cinema DSP HD3 performance and make the most of the capabilities of the speakers, they also support bi-amping for driving tweeter and woofer with separate amps. So, if you are looking for one of the best amps from Yamaha, this is it!
Specifications:
- 150 W per channel (8 ohms, 20 Hz-20 kHz, 0.06% THD, 2-ch driven).
- 170 W per channel (8 ohms, 1 kHz, 0.9% THD, 2-ch driven).
- Custom made, large-size toroidal transformer.
- Current feedback power amp with three stage Darlington circuit.
- 27,000F custom block capacitors.
- Symmetrical Power Amplifier Layout.
- Noise resistant XLR balanced connections.
- Bi-amping capability with channel selector.
- High quality gold-plated speaker terminals.
- Auto Power Standby.
- Detachable high quality thick AC power cord.
- Specially Designed High Rigidity Chassis and highest quality parts eliminates the effects of vibration for greater sound purity.
- Auto Power Standby.
- Handy Trigger Control for Synchronized Power On/Off.
- Speaker Impedance Selection.
Price: $2,999.95
