New SVS Ultra 13.4 driver

Buckeyefan 1

Buckeyefan 1

Audioholic Ninja
New SVS Ultra 13.1 driver

Here's a few pics of the new SVS Ultra 13.1 driver, compliments of "Sherv" aka ssabripo. It's quite a bit larger than the new Plus driver, wouldn't you say?

He also states "The SVS Ultra-13 will be front firing, just like the new NSD's, and the ports will be located in the front as well. ... They will be packaged initially with the new outboard EQ system AS-EQ1, which is a two channel version of the Audyssey MultiEQx Pro, specifically taylored for the LFE channel. VERY competitively priced, and will be an excellent budget option over the SMS-1."




Last edited:
Buckeyefan 1

Buckeyefan 1

Audioholic Ninja
Some quotes from Tom V. and Ron S.

Compliments of Home Theater Spot 11/21/06:

(this simply to update the forum members on the new SVS products we'll see in 2007)

>>>Value in audio is a funny thing, because the human emotional response to sound is non-linear. A piece of audio equipment can be measurably 90%, 95%, or even 110%, as good as another piece and yet not generate the same emotional reaction. Similarly a piece of audio equipment can cost $300 more than another, and because of the emotional impact of the sounds it generates, be judged a better value. That is how I see the TV-12 -- as actually the best value in the SVS line-up. And that is why I am going to be sorry to see it go.<<<


Hi GGunnell, Thank you for the insightful comments. We really value feedback like this from fellow audio enthusiasts!

Value is very tough to define as it represents a moving target of sorts…but I certainly understand your POV here.


>>>One trend I see in the future is that folks are going to have less and less space for stereo equipment. Construction costs and utility costs trending upwards at a faster rate are reducing the size of homes already. Another factor is the aging of the baby boomers -- more and more people are not going to want to deal with 140# cabinets. Larger drivers generally require larger cabinets. I'm sure the new TV-13 is a great driver -- and I hope it sounds as good as the TV-12 -- but it sounds like there's going to be a significant gap in both cabinet size and cost between the 12.3 series and the TV-13 series.<<<



The new PBUltra won’t be significantly larger than the current PBUltra. The revision I have in my theater room right now is about 5% larger for example. That may change very slightly…but this is very close to the final design. And this minor increase in size is accompanied by a substantial performance increase. The weight is still unknown…but again…don’t expect a huge increase over the current PBUltra. The new Ultra/2 will be a beast. It will be larger than the current Ultra/2…and heavier too. I have one of these pounding in my theater room right now(although it is a little earlier in the design process and may not be released at the same time as the single driver models). Like the single driver version…this represents a significant advance in performance capabilities. The pricing is going up(as Ron mentioned)…but the performance leaps here are so significant I believe most will consider the new Ultra designs to be an even BETTER value(compared to the current Ultra products).



>>>Spreading this gap even wider will be the growing popularity of multiple subs. My guess is that still very few sales go to multi-unit buyers, but those that run stereo (or more) subs are looking for quality sound in less expensive per unit enclosures. A 113 at $3k might possibly represent a performance value; but to get the acoustic benefits of stereo subs would require a minimum investment of $6k as opposed to around $2.5k for a pair of Ultras.<<<



Anything from JL is sure to be a quality product. The new(and current) Ultras are a different beast with different design goals though. If you are looking for the best performance from a relatively small enclosure in the $3000 range…The JL113 demands consideration. But if you are willing to accept a larger enclosure the new PBUltra will have huge performance advantages in the deeper bass frequencies(15-30hz) and we won’t be giving up much(if anything) in “upper bass slam factor) either..:)

The new Ultra driver (designed by Stephen Ponte) is a work of art. I’ve had the privilege of working with some of the best driver designer’s in the industry for the past decade and Stephen’s work is second to none and FAR superior to most. My longtime R/D partner Jim Farina is equally astute with his work on porting, amp design, enclosure design, ect. These two young engineers will be making waves in the industry for a long long time…mark my words here.

Also, remember that the new SB12plus is just the first design in the “small” subwoofer market for SVS. We’ll definitely expand that “family” of products in the future…although nothing is close to be finalized on those designs yet. This “family” definitely lends itself to the “multiple subwoofer” ideology of course.


Tom V.
SVS
...the overall dims of the single and dual Ultra-13 stuff will grow a bit. Not all that much bigger in the end, but it'll be a whole new orientation and form factor to a degree. Let's just say, a clear departure from whence we came.

If we don't have a prototype sub (which is a long shot at best) you'll most likely have some sketches to oggle, and barring that, "at least" the new Ultra-13 woofer. We'll have photos going live about that time too. In fact I spent most of yesterday setting up with our photographer to get that part ready. Lots to do still. Good thing CES comes right after Christmas (not ;^)

Ron
SVS

...A new PC-Ultra will be coming as we sell the last of the current (and still world-class) PC-Ultra's early in 2007. The "new" PC-Ultra will be difficult to spot from the "old" but it might actually beat the Powered Boxes out of the gate. It'll be the least expensive and still lightest/smallest-footprint Ultra sub for the immediate future. The PB13-Ultra will follow closely after and the new Ultra/2 will be at least a couple months behind that, since it has the most changes.

We just call the new driver the U-13.1 Ultra - 13", rev. 1. The idea being, there could be iterative versions down the road. As is our tendency, I don't see that happening unless we make a substantive revision/improvement. I think you'll like how it looks, and the new PB subs too, they are quite different than their predecessors in that regard, and only as big as they need to be (we know people consider the current models pretty large and heavy already, but we're taking steps to maximize the benefits of this size, and mitigate it aestetically too. The "dB" on the old subs was rumored to mean a lot of things. Like the Plus, the NSD/ISD, etc we tried lots of combinations to keep things straight. deci-Bell works, after our good friend Alexander (and the fact I type 'dB' about 100 times a day for support e-mail, manual work and the ocassional forum post probably led to that flourish in parts labeling). It's in the dustbin of SVS history now, all woofers have so much invested in staff time from all over the company that keeping things with product family nomenclature is easier to manage and ensures no one involved gets an inflated ego about their role in any component's development. You have the "SD" (standard driver" family, the "Plus" family, and the "Ultra" family).

Regardless of that, with the expansion of our product line, and website, and growing staff, we do indeed hope to spend more time showing off the people behind the product (PR types love that stuff too ;^). Anyone lucky enough to get out to CES will get a chance to chat with some of our talented folks. We ply them with double-time hours and bright lights once a year out in Las Vegas now just so that can happen ;^)

Ron
SVS

Last edited:
Sheep

Sheep

Audioholic Warlord
OMG, That is SWEET!

I can't wait to see the whole unit.

SheepStar

B

B5I8

Audioholic
Did TC Sounds develop this driver for them I wonder? I want to see what kind of amp they pair these new drivers with.

Sheep

Sheep

Audioholic Warlord
B5I8 said:
Did TC Sounds develop this driver for them I wonder? I want to see what kind of amp they pair these new drivers with.
Good question. While SVS's trend seems to be "all in house" with savings passed on to the customer, that drive looks like a textbook TC sounds unit.

SheepStar

S

ShaunH

Audioholic Intern
Hey guys here are some pics and specs. Here is a post from avsforum by ED Mullen.



Originally Posted by ManicMiner
I hope Ron, Ed or Tom will chime in to tell as more about the new Ultra, I have a TON of questions : )

-Why the switch to FF?
-Cone material?
-Price estimates?
-New amp technology?



1) Elimination of the base plate allowed a substantial increase in interior enclosure volume, which improves output/efficiency at the deepest frequencies.

2) Porting is triple 3.5" (about 15% more port area than dual 4") in the native 20 Hz tune, with 15 Hz, 10 Hz, and sealed tuning options.

3) The single driver Ultra products will feature BASH amps (power range is still being tweaked but expect anywhere 750-950 watts) with:

- RCA I/O with bypassable high pass for daisy-chaining
- XLR I/O with bypassable high pass for daisy-chaining
- variable low pass filter with bypass
- variable phase
- variable tuning switch (20/15/10/sealed)
- room gain compensation control

4) Ultra-13 Woofer Features:
• High-temp, flat-wire 3” US aluminum voice coil
• Polyimide impregnated fiberglass “former”
• Nickel-plated 1008 low-carbon steel motor components
• Copper “Faraday ring” for enhanced frequency response
• 13.5” Foam-core/glass composite cone (Polymethacrylimide)
• High-excursion parabolic SBR Surround, w/integrated top gasket
• Dual linear 9” Spiders, w/integrated lead wires
• Exclusive high-strength aluminum die-cast frame
• Chrome plated, spring-lock power terminals
• Low distortion, FEA optimized motor assembly
• Dual stack select grade ferrite magnets (Y-35)

5) Prices - TBD.


I can't post the the pfd about the eq ( to big) so I'll link to instead.

http://www.avsforum.com/avs-vb/attachment.php?attachmentid=72200


Attachments

Last edited:
I

Ilkka

Audioholic
I like the new look of it, curved front grill especially. Hoping to see it in real soon. :)

BTW, the code of the new driver isn't 13.4 but 13.1 instead.

"We just call the new driver the U-13.1 Ultra - 13", rev. 1. The idea being, there could be iterative versions down the road. As is our tendency, I don't see that happening unless we make a substantive revision/improvement."

Andreas

Andreas

Junior Audioholic
WOW!! Is that like looking at a car engine?

just wondering :))

mike c

mike c

Audioholic Warlord
i don't like the looks of the sub in post #7. what a relief, I thought I'd have to buy this one too :)

Buckeyefan 1

Buckeyefan 1

Audioholic Ninja
Sheep said:
That beast is sexy! Does it come in black? ;)

SheepStar
Front firing ports, just like Axiom. It's a nice looking unit. I bet it goes up in price another $250. ;)

mike c

mike c

Audioholic Warlord
i wish they put the ports somewhere else except the front (they look like triple sphincters)

j_garcia

j_garcia

Audioholic Jedi
It's a beauty. I don't care where the ports are as long as it sounds great.

Sheep

Sheep

Audioholic Warlord
mike c said:
i wish they put the ports somewhere else except the front (they look like triple sphincters)
What the heck do you care? Is your DD-18 no longer pleasing you?

PUHLEASE!

SheepStar

mike c

mike c

Audioholic Warlord
upgradeitis. :)

I want to move the DD to a music setup

anyway, when final pics are up ... and if I don't like the looks of the box, the cylinder should be cheaper too :)

Last edited:
Buckeyefan 1

Buckeyefan 1

Audioholic Ninja
A few more words of wisdom from Mr. Tom V...
Hi guys, the new Ultras will be available without the as-eq1. We don't have a final release date (or pricing) on the EQ1 yet. I'm hoping we can offer both (release dates/pricing---not begin shipping product) within 60 days.

Both single driver Ultras will ship in late 1st quarter/07 or 2nd quarter/07...pricing will be finalized very soon for those.

______________________________________________________________


Question posed to Tom V. >>>Are you far enough along with the single cabinets yet to make comparison with the single driver TV-12 Ultras?<<<

The new design will offer (about) 4.5 to 6dB more clean output (or approx the same as two of the older models), smoother response, better feature set, and will be only slightly larger (about 5% larger).
:eek: :eek: :eek:

T

Tex-amp

Senior Audioholic
I'd swear I heard Ron telling someone in the room at CES that the BASH amps aren't powerful enough for the 13 and they are doing something else.

The SVS/Audyssey room correction unit for $750 was very nice. It can measure 8 positions and correct 2 subs.

Buckeyefan 1

Buckeyefan 1

Audioholic Ninja
Just a rumor, but I'm reading where two single new Ultra's and the $750 AS-EQ1 will run around $3600 - $4000. That would make one single new Ultra $1425 to $1625 (subtracting out the AS-EQ1 and dividing by 2). I'm assuming that's in black. Shipping is another $99, and finished models may run another $100.

So if I wanted an Oak single Ultra, I could be looking at $1624 - $1824.

There is an $800 difference between the current Ultra and Ultra/2, so that could potentially make the new Ultra/2 $2424 - $2624.
