There's no link, so I'll just describe it here. I have to credit WmAx for the idea and procedure.
What you need:
2-3 Rolls Peel 'n Seal per speaker
3 bats 2'x4'x2" Mineral Wool
Cheap white speaker fluff (the kind that comes in bats, not loose) or thin (1") open cell foam
Leather work gloves
Good dust mask (or respirator if you wanna get fancy)
Safety Glasses
Utility Knife w/ Extra Blades
Cutting surface that won't dull a knife (ie NOT concrete if you can)
Old serrated kitchen knife (Ikea knives work wonderfully)
Rubber Mallet
Tape Measure
Screwdriver (Phillips and slot)
Time and Patience
Where to Get Materials:
Peel 'N Seal: Roofing Section of Lowes. It should be $13 and change for a 25'x6" roll.
Mineral Wool: Local insulation contractor, or you can try PMing WmAx. I know he has offered to ship the stuff at cost plus actual shipping. This is how I acquired mineral wool for my own mods.
Speaker Fluff/Foam: Any DIY site like Parts Express or Madisound. No need for fancy stuff, as it won't really be doing much.
Procedure:
1. Give your speakers the knuckle-rap test. Note the sound. Remove drivers from cabinet. You might need to pry them gently (hence the slotted screwdriver). Remove crossover and wires from cabinet (if possible, some are glued in). Remove anything else that you can that is not part of the cabinet or the port.
2. Measure the internal dimensions of the cabinet. If you think you can manage to stick Peel 'n Seal on the front baffle, more power to you, but you needn't worry about it.
3. Using your measurements, begin cutting pieces of Peel 'n Seal to fit. Do not install them yet! I made this mistake and it was hellish. Cut enough for at least six full layers on each wall. Be sure to cut out holes for the crossover and whatnot. Cut two pieces to wrap around the port to ensure that it does not resonate.
4. Grab one set of Peel 'n Seal pieces. Lay the first one on a sturdy surface, sticky side down, but still with the paper on. Remove the paper from the next sheet and place it on top of the first one, being sure to align it. Press down on the pieces and use the rubber mallet (if needed) to get them well-bonded. Repeat. Before adding more Peel 'n Seal to the newly bonded stack, install it in the cabinet. This stuff gets stiff when you stick a bunch of layers together, so installing it in 2-3 layer sets will ensure that it is cooperative. Once you get it in the cabinet, press it against the wall and get out the air pockets as best you can.
5. Repeat step 4 for all the internal faces of the cabinet.
6. Don your glasses, mask, and gloves. It's time to play with mineral wool! Re-measure the inside of the cabinet, but only one surface this time. Measure each side just before you install the mineral wool, as it will be easier to cut correctly sized pieces. Cut the mineral wool to size using the serrated knife, making sure to cut it just a little bit large. Doing this will allow you to forgo adhesive, instead holding the insulation in place by pressure and friction. Fill the cabinet almost completely with mineral wool, making sure to leave space for driver movement and enough room for the port to function correctly.
7. Cut your speaker fluff or foam to size to fit into the cabinet. It will function only as a filter to ensure that mineral wool fibers do not escape the cabinet. Place it in the cabinet as you see fit, keeping this purpose in mind. I personally used it to cover as much mineral wool surface as I could, though this is not necessary. I only went with this approach so I don't have to worry about it.
8. Cut some small pieces of peel 'n seal to wrap around the 'spokes' of the midbass driver frame. Many of these frames resonate, and this is an easy solution. Two layers should be sufficient.
9. Reinstall drivers, crossover, and any other components you removed. Give your speakers the knuckle rap test again. Is there a difference?
10. Enjoy your new(ish) speakers!
Points to note:
- This will void the warranty on your speakers.
- Don't laugh at the safety equipment. Mineral wool is nasty stuff. Razors are sharp.
- Keep in mind that you will lose some bass extension and overall output
I think that's it. Feel free to post more questions or shoot me a PM.
