My 3-way Build

Discussion in 'DIY Corner - Tips & Techniques' started by lsiberian, May 10, 2010.

  1. lsiberian Audioholic Overlord

    lsiberian
    Joined:
    Nov 17, 2008
    Messages:
    12,165
    Likes Received:
    3,155
    Location:
    On A Bridge in Fort Worth
    The build has begun this will be the interior structure of the speakers. They will be inside a constraint layer composed of roofing felt. Then an exterior plywood structure will be built around the interior structure. The bracing will be significant and their will be an 3" port.

    [​IMG]
    WinISD model

    [​IMG]
    Box notes was used to compute the interior the bracing is more

    [​IMG]
    Cuts were made with a circular saw connected to a shop vac to capture the nasty dust.

    [​IMG]
    Nicely stacked and cut.

    [​IMG]
    Clamps

    [​IMG]
    Glue

    [​IMG]
    Emerson tools straight edge

    Gluing is being done on the structure now.
    • Like Like x 5
  2. lsiberian Audioholic Overlord

    lsiberian
    Joined:
    Nov 17, 2008
    Messages:
    12,165
    Likes Received:
    3,155
    Location:
    On A Bridge in Fort Worth
    [​IMG]
    Clamp setup for back gluing

    [​IMG]
    Back Glued

    [​IMG]
    Lots of red oak braces.

    Next up is brace gluing
    • Like Like x 1
  3. darien87 Audioholic Ninja

    darien87
    Joined:
    Nov 13, 2005
    Messages:
    4,992
    Likes Received:
    950
    Location:
    Bay Area Cali, but San Diego is home
    Lookin' good dude. But didn't you say you were looking to go to Seminary school? Don't know if a future preist should be talking about doing 3-ways. :D
    • Like Like x 7
  4. lsiberian Audioholic Overlord

    lsiberian
    Joined:
    Nov 17, 2008
    Messages:
    12,165
    Likes Received:
    3,155
    Location:
    On A Bridge in Fort Worth
    wrong denomination. I'm baptist and happily married.

    :p The clean apartment is proof of marriage lol.
  5. Alex2507 Audioholic Slumlord

    Alex2507
    Joined:
    Dec 29, 2006
    Messages:
    15,028
    Likes Received:
    8,368
    Location:
    Past Hurt ... in recovery
    Give it time.

    [​IMG]

    You'll be wishing you were Mormon and designing 4-ways. :D
    • Like Like x 7
  6. Loren42 Audioholic

    Loren42
    Joined:
    Sep 14, 2008
    Messages:
    156
    Likes Received:
    49
    Be careful with that saw Eugene. Looks like a few toes missing already in that one picture. :D
    • Like Like x 1
  7. lsiberian Audioholic Overlord

    lsiberian
    Joined:
    Nov 17, 2008
    Messages:
    12,165
    Likes Received:
    3,155
    Location:
    On A Bridge in Fort Worth
    [​IMG]
    Rear braces glued. You can see there are 5 braces with around 3 inches between them.

    [​IMG]
    First side braces glued. The second will be cut once the vertical braces are glued.

    [​IMG]
    A view from the side.

    [​IMG]
    The snag was my glue started running really low. I'll need to get some more glue to continue with the vertical braces and the others.
  8. lsiberian Audioholic Overlord

    lsiberian
    Joined:
    Nov 17, 2008
    Messages:
    12,165
    Likes Received:
    3,155
    Location:
    On A Bridge in Fort Worth
    Another phase of bracing done. If I had a miter saw it would be much easier, but I've made due with the circular saw.
    [​IMG]

    [​IMG]

    Next is sealing seams and adding some extra bracing with the scrap wood.
  9. lsiberian Audioholic Overlord

    lsiberian
    Joined:
    Nov 17, 2008
    Messages:
    12,165
    Likes Received:
    3,155
    Location:
    On A Bridge in Fort Worth
    The interior front baffles are done.
    [​IMG][​IMG]

    next up is the constraint layer damping application.
    [​IMG]
  10. lsiberian Audioholic Overlord

    lsiberian
    Joined:
    Nov 17, 2008
    Messages:
    12,165
    Likes Received:
    3,155
    Location:
    On A Bridge in Fort Worth
    constraint layer damping

    [​IMG]
    [​IMG]
    [​IMG]
    [​IMG]

    constraint layer damping applied to everything but the front baffle.
  11. Alex2507 Audioholic Slumlord

    Alex2507
    Joined:
    Dec 29, 2006
    Messages:
    15,028
    Likes Received:
    8,368
    Location:
    Past Hurt ... in recovery
    Only one layer of Peal & Seal? :eek:

    Now is the time for the second layer. ;)

    Then the third layer. :D
  12. lsiberian Audioholic Overlord

    lsiberian
    Joined:
    Nov 17, 2008
    Messages:
    12,165
    Likes Received:
    3,155
    Location:
    On A Bridge in Fort Worth
    So far :D I can't tell from Chris's pictures how many layers he uses and he's got that injury.
  13. Alex2507 Audioholic Slumlord

    Alex2507
    Joined:
    Dec 29, 2006
    Messages:
    15,028
    Likes Received:
    8,368
    Location:
    Past Hurt ... in recovery
    It's more than one ... :rolleyes:

    Now get back to the store and buy some more. :D
  14. lsiberian Audioholic Overlord

    lsiberian
    Joined:
    Nov 17, 2008
    Messages:
    12,165
    Likes Received:
    3,155
    Location:
    On A Bridge in Fort Worth
    I gotta say I don't know when I'll get this finished at this point. I've gone around about building amps, but I think I want to use a passive crossover for the top point to simplify. 5khz is the crossover point for the tweeter 4th order L-R was the plan. Their will be dual Dayton RS-252 in parallel crossed with the RTI tweeter. My goal here is to simplify this build as much as I can. It's overly complex to setup as is. I may end up selling it or giving it away at some point.

    I think only needing 2 amps and 1 crossover for it would make it far more appealing. IOTW having second thoughts.

    1. Implementing the port is gonna be a pain.
    2. Crossover topology is overly complex
    3. I'm satisfied with the current setup I have.
  15. annunaki Moderator

    annunaki
    Joined:
    Dec 9, 2003
    Messages:
    4,326
    Likes Received:
    1,410
    Location:
    Wausau, WI
    You will want a minimum of 1/8" peel & seal, but 1/4" works better, and would be all that is necessary.

    Make sure to go over the metal backing with some 400 grit sand paper to ensure good adhesion of the second layer.
    Last edited: Jul 7, 2010
  16. Alex2507 Audioholic Slumlord

    Alex2507
    Joined:
    Dec 29, 2006
    Messages:
    15,028
    Likes Received:
    8,368
    Location:
    Past Hurt ... in recovery
    Maybe you can get one of the mods to ban you until you complete these speakers.
    Oh, look who showed up!

    That's like 2 more layers and probably 3. It is work but at least you see what's involved when you suggest that others do this, that, or the other. Nothing is easy or quick.

    You might want to glob some construction adhesive on the braces to fill the little spaces. Also you might want to run a bead of adhesive in the corners of the inside of the cabinet to insure that you don't have air leaks. Push the bead in with your finger to press it up against the walls. It would have been easier without the braces.

    Can we get some more pictures of your feet ... for Greg? :D
  17. lsiberian Audioholic Overlord

    lsiberian
    Joined:
    Nov 17, 2008
    Messages:
    12,165
    Likes Received:
    3,155
    Location:
    On A Bridge in Fort Worth
    LOL. I already sealed the seams with caulk before I put the braces in.
  18. haraldo Audioholic Spartan

    haraldo
    Joined:
    Feb 25, 2008
    Messages:
    6,335
    Likes Received:
    1,217
    Nice project mate, can't wait to see the finalized speakers, would even more enjoy to hear :D

    Looks like there's no end to the surprises and feedback you get once you visualize your DIY project on AH :p

    The first pic, does that show a vacuum cleaner or is it the woofer :p

    2 layers of damping, how much is that gonna add in weight to your speakers?
  19. lsiberian Audioholic Overlord

    lsiberian
    Joined:
    Nov 17, 2008
    Messages:
    12,165
    Likes Received:
    3,155
    Location:
    On A Bridge in Fort Worth
    I think I will get it done eventually. The problem is always cost I still want to add to more two Dayton midrange dome drivers and will need 5 more channels of amping.

    Building it is the fun part, but paying for stuff to make it work at reference level is a pain. Once I complete it I plan to redo my RB kits for surround and center duty.

    It looks like I might get a DCX as a christmas gift though. Oh the dreams. Since I'm also talking about doing the BBY payment plan thing to replace my projector once my wife runs the bulb out. Ignore that last post. Greek has had me thinking a little wildly. It took me a year to build the sub after all.
  20. lsiberian Audioholic Overlord

    lsiberian
    Joined:
    Nov 17, 2008
    Messages:
    12,165
    Likes Received:
    3,155
    Location:
    On A Bridge in Fort Worth
    I got that and the acetone. I want to get the front baffle mounted before I do another layer. I still haven't figured out what I want to do with the binding posts, but I suppose that is all in good time.
